SEMI FRAMELESS

High Quality MASTER RANGE hardware. LATCHES TO SUIT MOST CONFIGURATIONS. No holes needed in the hinge panel  However, holes are needed in the gate panel. See above pictures to show hole placement in the gate panel.    see above pictures for details and gap...

The Master Range Gate Hardware is designed to suit the 8mm and 10mm toughened glass gates and 12mm hinge panels. Our glass panels have holes to suit the Master Range Hardware. (please see other listings)     When choosing your gate hardware, first you will need to design your...

8mm clear toughened pool gate,  Polished edges 2mm radius corners pre drilled for hinges and latch 6 x 10mm holes, (suits master range hardware) 8mm gates are lighter than the 10mm gates and will lead to less wear and tear on the hinges.  ...

• 106x106mm outer - 52x52mm inner - Alloy ADC12 • Suits screw fixed base plated posts - does not suit welded 134x100mm base plated posts or 115x100mm base plate sets • Cover can be fitted to posts after fence is installed

TECH SPECS• Alloy 6063 – T6 • 1.8mm wall thickness with 3mm ribs • Screw flutes to screw on base plate if required • Aluminium powder coated press-in top plate included with 2400mm posts • lxx = 170.44 x 10E3 mmE4 • lyy =...

Each pack contains 10 lengths at 1300mm long.  Suits our semi frameless pool fence posts.  Choose the rubber type you need depending on your glass thickness.  See pic for more info.

Suits 8mm or 10mm glass Choose from Round Post or Square Post / Wall A pair of hinges will support a glass door that weights up to 25kg Sold as a pair.

• Simply screw base plate onto core drill post • Australis post extrusion specially designed with screw flutes, will fit our semi frameless posts. and 50 x 50mm posts with screw flutes.  • 4x 12G x 50mm long CSK screws included in set •...

• Rubber glazed into 1 side of post extrusion pocket and/or glazing rail (opposite side to captive wedge rubber) • Suits 12mm glass with Australis series

• Premium 2205 grade stainless steel • Gaskets included to suit 8mm, 10mm or 12mm glass • Gaskets made from EPDM - highest quality gaskets available • Can be used with bottom seat (refer below)

• Suits face mount application - Use when hinging off the front face of a wall/post • Cone cap incorporated to prevent toe hold • Suits 8mm and 10mm glass gates • Weight capacity of 25kg per pair • Includes SS316 plate (on opposite...

• Alloy ADC12 • Suits our aluminum semi frameless pool fence base plated posts

• Slimline 45x45mm shape • Premium grade SS2205 in polish or satin finish • Gaskets included to suit 8mm or 10mm glass only (not suited to 12mm glass) • Gaskets made from EPDM - highest quality gaskets available

Vinyl wedge roller tool,   Perfect for rolling and pushing rubber gaskets into windows, or pool fencing.

• Suits all 50x50mm core drill posts • 100mm x 100mm outer - 52mm x 52mm inner

• Separates bottom edge of glass from aluminium infill • 4mm thick - pack of 20 • Simply push into glazing pocket Glass will sit on this block

• Alloy 6063 - Temper: T6 • Infill suits all Australis glazing posts • Snap-in infill to set start point of glass height • 1400mm or 2800mm high, cut to size.    Free collection from Gold Coast, Brisbane, Adelaide, Melbourne, Cardiff or Perth Delivery...

100 metre rolls of glazing wedge. Suits our semi frameless pool fence posts.  Choose the rubber type you need depending on your glass thickness.  See pic for more info.

• 90 degree extrusion profile in Alloy 6106 T6 with 2.5mm wall thickness• Suitable for 8, 10 or 12mm thick glass with applicable glazing rubbers• Available lengths – 1400mm• 1400mm long includes top cap. • Features 4 x screw flutes in extrusion – ideal for...

One way extrusion profile in Alloy 6106 T6• Features 2 x sides with 3.7mm wall thickness for maximum strength• Suitable for 8, 10 or 12mm thick glass with applicable glazing rubbers• Available lengths – 1400mm or 5800mm• 1400mm long includes top cap. • Features 4...
