40 x 40mm Radiator Fence Panel – 40mm Gap | Aluminium Batten

Aluminium Batten Fence Panel (Radiator Style) – Custom Made

40 x 40mm battens | 40mm spacing | Custom widths up to 2400mm

Create a premium architectural finish with our custom aluminium batten fence panels, designed to deliver strength, style, and increased privacy.

Featuring a high-privacy 40mm spacing and a premium face-welded “radiator” design, these panels provide the perfect balance of security, airflow, and modern aesthetics—ideal for residential and commercial projects.

• ✔ Made to order
• ✔ Maximum privacy design (tight 40mm spacing)
• ✔ Strong and lightweight aluminium
• ✔ Low maintenance design
• ✔ Custom widths up to 2400mm

Why Choose These Fence Panels?

Maximum Privacy Design

The tight 40mm spacing provides increased privacy and reduced visibility, making it ideal for boundary and screening applications.

Modern Architectural Appearance

The face-welded extrusion system creates a dynamic “radiator” look that changes depending on your viewing angle, delivering a premium finish.

Built for Strength & Longevity

Manufactured from 6063 T6 aluminium, these panels are corrosion-resistant and suitable for Australian coastal and inland environments.

Fully Custom Made

• Widths from 250mm to 2400mm
• Multiple height options
• Choice of batten spacing and styles

Designed for Complete Systems

Part of a full fencing solution including matching swing gates, sliding gates, posts, and accessories.

Key Features

• Face-welded aluminium battens
• 30 design combinations (10 styles × 3 spacing options)
• Premium powder coated finish
• Rust-proof aluminium construction
• Low maintenance – no repainting required

Colour Options

Available in a wide range of powder coated finishes:

• Pearl White
• Surfmist
• Shale Grey
• Dune
• Silver Pearl
• Primrose
• Jasper
• Woodland Grey
• Ironstone
• Monument
• Satin Black
• Basalt

General Specifications

• 40 x 40 x 1.8mm rails
• 40 x 40 x 1.4mm pickets
• Face welded onto rail

Product Specifications

• Material: Powder Coated Aluminium (6063 T6)
• Heights: 900mm, 1200mm, 1500mm, 1800mm, 2100mm, 2400mm
• Widths: 250mm – 2400mm
• Tubes: 40 x 40 x 1.4mm Screwflute SHS
• Edge: 2mm radius
• Spacing: 40mm
• Weld: Face welded onto rail (T6061 Aluminium)
• Caps: Cast caps (top only)
• Powder Coat: Interpon standard range
• Brackets: 40 x 40mm single lug (sold separately)

Applications

• High-privacy boundary fencing
• Front fencing
• Side fencing
• Architectural screening

Lead Time

Approx. 2–3 weeks (made to order)

FAQs

Are these panels suitable for coastal areas?

Yes, aluminium is corrosion-resistant and performs well in coastal environments.

What is the maximum panel width?

Up to 2400mm depending on configuration.

Does tighter spacing improve privacy?

Yes, the 40mm spacing provides increased privacy compared to wider spacing options.

Do you supply matching gates?

Yes, matching swing gates, sliding gates, posts and accessories are available.

Is installation easy?

Yes, the pre-welded system is designed for straightforward installation.

Need Help?

Send us your measurements or plans and we’ll recommend the perfect fencing layout

The Batten Radiator Fencing Range is an easy-to-install pre-welded system with a wide range of extrusion and small, medium and large spacing options.

Face-Welded Extrusion Options

Extrusions are face-welded to horizontal rails, giving a contemporary 'radiator' look and creating an ever-changing privacy element when viewed from different angles.

Get the Look

Consisting of a unique range of panels, swing gates, sliding gates, posts & accessories, the Radiator Fencing range is the perfect choice in architectural design & functionality.

Coat to Order

On Trend Powdercoating Colours

The Aluminium Batten Radiator Fencing is powder coated to order and is available in a range of Interon Powder Coating colours. The best colour for your aluminium fencing will depend on your home's colour scheme and your preferences. Below are some of our most popular on trend Powder Coating colours:

General Specifications:

• 40 x 40 x 1.8mm Rails
• 40 x 40 x 1.4mm Pickets
• Face Welded onto Rail

Product Specifications:

Lead Time: Approx. 2–3 weeks
