Adjustable angle Glass to Wall Frameless shower door hinge, 8 - 12mm glass, very high quality

The Glass House Adjustable Series has taken our popular Geneva Hinge to a new level. Adjustment to accommodate the desired angle (up to 90 Degrees ) is done after the door is installed. Once the door is hung, simply loosen the Allen set screws and turn the door to the desired closed position. By merely tightening the Allen screws your door will self-center to the desired closing position. The door can swing 90 Degrees inward and 90 Degrees outward (adjusting angle from factory set position will reduce 90 Degrees swing in that direction). For doors pulling outwards only (using a clear door jamb), you can adjust the hinge to close 5 Degrees inside the shower area, thus having the door close snugly against the jamb.

Price is per hinge

Using two hinges: with 8 to 12mm glass the hinge will hold up to 36 kg with a maximum door width of 711mm
Using three hinges: with 8 to 12 mm glass the hinge will hold up to 54 kg with a maximum door width of 813 mm

SPECIFICATIONS:

• Glass Thickness: 5/16" (8 mm) to 1/2" (12 mm) Toughened Safety Glass
• Special Features: Adjustable to any angle up to 90 Degrees without having to take door down.
• Construction: Solid Brass
• Hinge Swings: 90 Degrees in and 90 Degrees out (at factory set position).
• Closing Type: Self-Centering when within 15 Degrees of closed position.
• Cut-Out Required Includes: Gaskets, Screws, and Glass Fabrication Dimensions. Gasket Pack must be purchased separately for use with 8mm thick toughened glass.

NOTE: Door glass width may require alteration from standard clearance deductions when adjusting angles.
