Adjustable Semi-Frameless Shower Screen - 6 mm glass - Choice of sizes.

Please see pictures above for sizing.

1950mm high, (Height is not adjustable)

• Grade ‘A’ toughened glass - AS/NZS2208 compliant Door & return panel 6mm clear toughened; fixed panel 5mm clear toughened - Silk screen compliance logo on glass

• Pivot hinges - High quality Stylish square shape; smooth function and minimal friction for ease of operation Pivot door allows for overlap of fixed panel =  water seal
• Fully frameless door with round knob Modern fully frameless 6mm clear toughened door Door knob is chromed aluminium for durability (not chromed plastic)
• Slimline strong aluminium frame Silver polished frame with minimalist low profile framing system
• Fully reversible door - left or right opening Simply flip and rotate pre-assembled fixed panel with door to suit left or right opening - so easy!
• U channels allow flexibility for installation Slimline profile U channels allow installation for out of square wall situations Additionally U channels allow 20mm extra width adjustment
• Install on tiles or shower bases
• Return panel install is so easy Simply slide the innovative 90 degree adapter into inline panel
• Easy telescopic adjustment: WIDTH ADJUSTABLE Innovative design allows extrusion to telescopically move in & out for door width adjustment
• Comprehensive internal carton packing to minimise transport and storage damage

Front section (with door) (when ordering without a return panel)

800mm option adjusts from 795mm - 850mm

850mm option adjust from 845mm - 900mm

900mm option adjusts from 885mm - 990mm

1050mm option adjusts from 985mm -  1090mm

1200mm option adjusts from 1085mm - 1230mm

1350mm option adjusts from 1225mm - 1370mm

1500mm option adjusts from 1400mm to 1550mm

Thickness of front section frame is 25mm

Return Panel Sizing

850mm x 1950mm   adjusts in wall channel from 830 - 850mm

890mm x 1950mm   adjusts in wall channel from 870 - 890mm

910mm x 1950mm   adjusts in wall channel from 890 - 910mm

1010mm x 1950mm   adjusts in wall channel from 990 - 1010mm

 Thickness of return frame is 11mm
