VersaTilt Standard Channel Balustrade and Pool Fence Kit – 4200mm

The VersaTilt Standard Channel Balustrade Kit provides a premium aluminium channel system for frameless glass balustrade installations. Manufactured from high-quality architectural-grade aluminium, the system is designed for strength, durability, and streamlined installation.

Features

• Clear anodised aluminium channel, 4200mm length (6063-T6)
• Aluminium covers, 4450mm length (6463-T5)
• Available in mill finish or brushed satin finish
• Pre-machined elongated fixing holes for faster installation
• Includes both full and top cover options (unused covers can be discarded)
• Suitable for 12mm glass installations with included glazing rubbers

Compliance & Certification

Important: Ensure all installations comply with current building regulations, including glass selection and fixing requirements. Updated Australian balustrade regulations came into effect on 1 May 2023.

If you are uncertain about compliance requirements, consult your building certifier before installation.

An engineered balustrade design is available for the VersaTilt Standard Channel Balustrade system.

Depending on your project's location and certification requirements, either:

• Standard balustrade design documentation may be sufficient, or
• Site-specific engineering certification may be required (for example, Form 15 in Queensland or Regulation 126 requirements in Victoria).

The purchaser is responsible for ensuring the selected balustrade products are suitable for the intended installation and comply with all relevant regulations and certification requirements.

Do not install balustrade products until all certification requirements have been confirmed and approved.

Kit Includes

• 1 × 4200mm aluminium channel
• 1 × 4450mm side cover
• 1 × 4450mm top cover
• 1 × 4450mm bottom infill
• 2 × 4450mm glazing rubbers for 12mm glass

Sold Separately

The following components must be ordered separately where required:

• End plates
• Top fill dividers
• Joining pins
• Glazing rubber for 15mm glass
• Pressure plates

Collection & Delivery

Free Collection Available From

• Gold Coast
• Brisbane
• Adelaide
• Melbourne
• Cardiff
• Perth

Local Delivery Areas

• Sunshine Coast (north to Noosa)
• Brisbane
• Gold Coast
• Tweed Region
• Northern Rivers (north of Ballina)
• Melbourne Metro
• Adelaide Metro
• Cardiff Metro
• Perth Metro

Please check our delivery maps to confirm service availability.

If your location falls outside these areas, please contact us for a delivery quote and availability.

Frequently Asked Questions

What glass thickness is compatible with this balustrade channel?

This VersaTilt Standard Channel Kit includes glazing rubbers suitable for 12mm glass. If using 15mm glass, compatible glazing rubber must be ordered separately. See our heavy duty system here for use with thicker glass options,

Does this balustrade system comply with Australian building regulations?

The system is designed for use in compliant balustrade installations; however, compliance depends on factors including glass type, fixing method, installation location, and project requirements. Always confirm compliance with your certifier before installation.

Is engineering documentation available?

Yes. An engineered balustrade design is available for the VersaTilt Standard Channel Balustrade system.

Do I need site-specific engineering certification?

Certification requirements vary by state, project type, and installation location. Some projects may only require standard engineering documentation, while others may require site-specific certification such as Form 15 (QLD) or Regulation 126 documentation (VIC).

What is included in the 4200mm channel kit?

The kit includes:

• 1 x 4200mm aluminium channel
• 1 x 4450mm side cover
• 1 x 4450mm top cover
• 1 x 4450mm bottom infill
• 2 x 4450mm glazing rubbers for 12mm glass

What components are sold separately?

End plates, top fill dividers, joining pins, pressure plates, and glazing rubber for 15mm glass must be purchased separately if required.

Can the channel be used for frameless glass balustrades?

Yes. The VersaTilt Standard Channel System is designed for frameless glass balustrade installations when used with compatible glass and fixing methods.

What aluminium grade is used in the channel?

The channel is manufactured from 6063-T6 clear anodised aluminium, while the covers are manufactured from 6463-T5 aluminium.

Where can I collect my order?

Free collection is available from Gold Coast, Brisbane, Adelaide, Melbourne, Cardiff, and Perth.

Do you deliver outside your local delivery areas?

Delivery is available throughout selected metro and regional areas. If your location is outside the listed delivery zones, contact Glass House AU for a delivery quote and availability.

What finish options are available?

The aluminium covers are available in either mill finish or brushed satin finish.
