PVC - Full Privacy Fencing Panel Kit 2388mm wide x 1800mm high. (Posts Purchased Separately)

Full privacy, PVC fence panel 1800mm high,
perfect for boundary fences

A flat-packed PVC privacy fence panel kit that builds one 2388mm-wide by 1800mm-high boundary fence bay. Delivery is limited to Sunshine Coast (as far north as Noosa), Brisbane, Gold Coast, Northern Rivers (north of Ballina), Tweed, Melbourne metro, Adelaide metro, Cardiff metro and Perth metro; ask before ordering if you're outside these areas. It ships in a box and includes one top rail, one bottom rail (with an aluminium insert for rigidity), eight tongue-and-groove vertical panels and two U channels to finish the bay's ends. The white, UV-stabilised PVC will not rot or warp, and both rails and panels can be cut down in width or height to fit a smaller bay. Posts are not included and must be purchased separately; choose a post that matches your fence line and confirm it suits this kit's rail profile before ordering.

Will not rot or warp.

• Flat pack kit in a box - easy assembly
• White UV stabilised PVC with protective titanium dioxide additives
• Panels have stylish shiplap grooves, are tongue & groove and slot neatly into each other
• Horizontal Rails: 2388mmW x 152mmH x 50.8mmD;
  2.3mm wall thickness
• Bottom rail includes aluminium insert for extra rigidity
• Vertical Panels: 1565mmH x 289mmW x 22mmD;
  1.3mm wall thickness
• Achieves overall panel height of 1800mm
• Panel and rails can be easily cut in width and height

• 1 x top rail (2388mm wide)
• 1 x bottom rail (2388mm wide) with an aluminium insert for extra rigidity
• 8 x vertical panels (1565mm high x 289mm wide)
• 2 x U channels (1495mm high) to finish off both ends of the panel

Please ensure you are in our local delivery area, ask if unsure.

Delivery is to the below areas only,

Sunshine Coast, (As far north as Noosa)

Brisbane,

Gold Coast,

Northern Rivers, (north of Ballina)

Tweed

Melbourne metro

Adelaide metro

Cardiff metro,

Perth metro

If outside of these areas please ask.

Common questions about the PVC Full Privacy

 Fencing Panel Kit

What exactly is in this PVC fencing panel kit?

One 2388mm-wide by 1800mm-high boundary fence bay in flat-packed white PVC: a top rail, a bottom rail with an aluminium insert, eight tongue-and-groove vertical panels, and two U channels to finish the bay's ends.

Each flat-packed kit contains:

• 1 × top rail, 2388mm long.

• 1 × bottom rail, 2388mm long, with an aluminium reinforcing insert.

• 8 × tongue-and-groove vertical panels, each 1565mm high × 289mm wide.

• 2 × U channels to finish the panel ends.

The assembled panel achieves an overall height of 1800mm. Posts are purchased separately. View the panel kit specifications. Although, this is easy to cut down.

Who is this PVC fence panel kit suited to?

This kit is a practical choice for homeowners creating a private

backyard or replacing a boundary fence, and for fencing installers and capable DIYers.

For DIY installation, you should be comfortable measuring and setting out a fence line, securing posts, keeping components level and cutting panels where required. If you are unfamiliar with these tasks, we recommend using an experienced fencing installer.

What posts does this fence panel kit need?

Use the 127 × 127mm Full Privacy PVC posts, selecting the configuration to suit your fence layout:

These posts have 153 × 52mm rail openings, matching the kit’s 152 × 50.8mm rail profile. Post caps are sold separately.

Does the kit include everything needed to install the fence, including fixings?

No. The kit includes the rails, vertical panels and U channels. You will also need matching posts, post caps and the materials required to secure the posts for your installation.

When would this PVC panel kit be the wrong choice?

Choose another option if you need a colour other than white, an open fence that preserves views, or a panel taller than 1800mm.

The rails and infill can be trimmed for a smaller panel. Longer fence runs require additional bays and supporting posts. When planning post spacing, allow for the rails inserting into the posts; the 2388mm rail length should not be treated as the clear opening between posts.
